2005-15 Hilux 3" Build up kit

  • Image 1
  • Hilux 05+ 3" Touring Lift kit
  • Tough Dog Adjustable Front Struts / coils
  • Front Coils and Spacers
101.00 KGS
Calculated at checkout


The Snake Racing 3" Build up kit allows you to choose all the parts required to lift the front or rear of your 2005-2015 Toyota Hilux.

Offering options on every component this kit allows you to build and use any or all of the parts required to obtain 3" of lift.

Giving you lift and clearance for 33" tyres (with the correct rim size /offset)

You build the kit to suit your requirements from a basic to a fully optioned off road truck with all the options for maximum wheel travel.

Options to upgrade to Pre-assembled front struts and springs will save time and money on your install and get NEW strut top hats!

Choose between foam cell or 9 adjustable shocks, Braided Brake Lines, drop diff kit in the front ( recommended for any 3 inch front lift) and Adjustable upper control arms for maximum unbound wheel travel and wheel alignment specs.

Choose the rear end parts you want from Springs, bushes, u bolts, greasable shackles, braided brake lines and your choice of foam cell or 9 stage adjustable shocks.

If you plan to install a 33" tyre (285/75) or bigger we recommend adding Adjustable upper control arms. This will improve wheel clearance to the firewall and allow more unbound wheel travel all while offering maximum wheel alignment options.

An easy bolt on kit that comes complete with all fitting hardware studs, washers and nuts required for lifting any 4x4 Hilux 2005-2015 o SR or SR5 model.

Choose the right coil spring rate options for your Hilux

Parts List

  • 2 x Tough Dog Front Struts
  • 2 x Tough Dog Coil Springs
  • 2 x Alloy Strut Spacers (Australian Made!)

Optional Parts

  • Snake Racing Front Braided Brake Line Kit (Australian Made!)
  • Snake Racing Drop Down Diff Kit (Australian Made!)
  • Pre-assembled struts
  • Adjustable upper control arms - recommended if installing 285/75 tyres
  • Rear springs select your weight options
  • rear bush kit
  • rear u bolts kit
  • rear shocks
  • braided brake line kit
  • gresable shackles

Coil Spring Option

  • Medium Duty coils - no bull bar
  • Heavy Duty coils - Bull bar / Winch
Note; vehicle requires wheel alignment after installation of this suspension kit.
